Features
Digital display of sheet thickness and operations parameter
Programmable for 60 different materials and thicknesses
Selectable interfaces:
- Opto coupled 8-Bit PLC parallel-interface for input and output
Opto coupled RS 232 interface for data documentation with a PC-Computer
Documentation and analysis of measurement data with RPC software
Technical data
|
Applications: |
Continuous sheet thickness measurement of steel coils
Cost effective tried and proven solution for coil lines especially for prossesing tinplate |
|
Material thickness: |
Steel: .05 - 3.50 mm (.002 - .15in.) |
|
Measuring method: |
single sided contact |
|
Functional principle: |
Permanent magnet |
|
Programs: |
60 |
|
Special features: |
RPC-Software for analysis of measurement data |
