Features
Digital display of sheet thickness and operations parameter
Programmable for 60 different materials and thicknesses
Selectable interfaces:
- Opto coupled 8-Bit PLC parallel-interface for input and output
Galvanically isolated RS 232 interface for data documentation on a PC-Computer
Documentation and analysis of measurement data with RPC software
Technical data
|
Applications: |
Precision thickness gauging of coils and blanks, e.g. in front of stamping presses, in cut-to-length or slitting lines |
|
Material thickness: |
Non-ferrous: 0.05 - 15.0 mm (.0002 - .600in.)
Especially well suited for non-magnetic stainless steel (austenitic material) |
|
Measuring method: |
dual head non-contact |
|
Functional principle: |
Inductive transmission principle |
|
Programs: |
60 |
|
Special features: |
RPC Software for the analysis of measurement data |
